ITG GO-09 Oxygen Sensor | M-09 Oxygen Sensor | Original Medical O2 Cell

The GO-09 Oxygen Sensor (also recognized as the ITG M-09 model) is a premium, German-made medical oxygen cell designed for high-precision O2 monitoring in anesthesia workstations, ventilators, and portable oxygen analyzers. Manufactured by IT Dr. Gambert GmbH (ITG), this galvanic electrochemical sensor delivers exceptional long-term stability and linear output, making it a critical component for hospital respiratory care and divers’ gas analysis equipment.

Key Features & Advantages:
– OEM Quality: Genuine replacement sensor from ITG Germany, ensures 100% compatibility with original clinical monitors.
– Secure Connection: Built-in cable harness with a 3-pin Molex connector prevents accidental disconnections and signal noise.
– Acidic Electrolyte Technology: Highly resistant to carbon dioxide (CO2) cross-interference, ensuring accurate O2 readings in anesthesia environments.
– Self-Powered Galvanic Cell: Generates its own voltage output proportional to oxygen partial pressure, requiring no external driving power.

Comprehensive Technical Specifications:
– Brand: ITG (IT Dr. Gambert GmbH, Germany)
– Model Name: GO-09 / M-09 (Part Number: 410009)
– Measurement Range: 0 to 100% Vol. O2 (Oxygen Concentration)
– Sensor Principle: Electrochemical Galvanic Cell
– Signal Output in Ambient Air: 9.0 mV to 13.0 mV (at 20.9% O2, 1013 mBar)
– Response Time (T90): Less than 15 seconds
– Response Time (T97): Less than 30 seconds
– Measurement Accuracy: Meets DIN EN ISO 80601-2-55 standard specifications
– Linearity Error: Less than 2% of full scale
– Zero Offset Voltage: Less than 0.1 mV in 100% Nitrogen (N2)
– Electrical Interface: 3-pin Molex connector on integrated wire harness
– Operating Temperature Range: 0 deg C to 40 deg C
– Storage Temperature Range: -20 deg C to 50 deg C (Recommended: 5 deg C to 30 deg C)
– Ambient Pressure Range: 750 to 1250 hPa
– Expected Operational Life: Greater than 500,000 Vol.% h O2 (Approx. 2-3 years in ambient air)

Cross-Reference & Compatibility Guide:
This ITG GO-09 Oxygen Sensor seamlessly replaces the following OEM part numbers and device cells:
– MSA (Mine Safety Appliances): MiniOx I, MiniOx II, MiniOx III, MiniOx IA Analyzers
– OxyCheq: Expedition-X O2 Analyzer, Expedition-X Pro
– ITG Germany: M-09, Type M-09 Medical O2 Cell
– Spectrum: 410009 Replacement Cell

Frequently Asked Questions (FAQ):

Q: Are the ITG GO-09 and M-09 sensors completely identical?
A: Yes, GO-09 and M-09 represent the exact same medical-grade oxygen cell from ITG Germany. They share identical mechanical styling, chemical composition, and 3-pin Molex wiring parameters.

Q: How should the GO-09 oxygen sensor be stored when not in use?
A: It should be stored in its original sealed package at temperatures between 5°C and 30°C. Never freeze the sensor, and avoid exposing it to high concentrations of volatile organic solvents.

Q: Does this sensor come pre-calibrated from the German factory?
A: Every single unit undergoes strict QA testing and temperature compensation calibration in Germany. However, for clinical safety, always perform a standard 21% air or 100% O2 calibration on your monitor upon initial installation.
